Highly Insulating 95% Alumina Ceramics With Volume Resistivity Of Ge 1014 Omega

Name: Highly Insulating 95 Alumina Ceramics With Volume Resistivity Of Ge 1014 Omega
Brand: HENGYUAN
Price: 1 USD

China Highly Insulating 95% Alumina Ceramics With Volume Resistivity Of Ge 1014 Omega wholesale

Brand Name : HENGYUAN

Model Number : 95% Alumina Ceramics

Certification : CE,UL

Place of Origin : WUXI JIANGSU CHINA

MOQ : 100

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 5000 PCS/WEEK

Delivery Time : 20 DAYS

Packaging Details : Carton

Material : 95% Alumina Ceramics

Color : White

Weibull Modulus : 10M

Modulus of Elasticity : 340 Gpa

OEM，ODM : Acceptable

Orgin : WUXI JIANGSU CHINA

MOQ : 100 PCS

Package : Carton

Contact Now

Alumina ceramic is a kind of ceramic material with alumina as the main body, which has a variety of superior properties. First of all, its hardness is very large, second only to diamond, far exceeding the wear resistance of wear-resistant steel and stainless steel. Secondly, its wear resistance is excellent, which can greatly extend the service life of the equipment.

Naterial	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardulus	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
*Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric constant	εr	10	10	10	10

Highly Insulating 95% Alumina Ceramics With Volume Resistivity Of Ge 1014 Omega
